Product  REI-E-111T6C-2B2000-C

passive junction

Order number: 6602068
    • Junction box for wall mounting with stainless steel M12 receptacle connections
    • Integrated terminating resistor (switchable)
    • Cable shielding: capacitive or direct connection to housing potential selectable via switch
    • Isolated support terminal for optional protective conductor incorporated in cable
    • Passive junction, 8-port
    • Protection class IP67
    • 1 × 7/8" male connector
    • 1 × 7/8" female connector
    • M12 × 1 female connector
#
Hide All Open All

General data

EAN 4047101020342
eCl@ss-Code (V5.1.4): 27250201 -/- Network components (fieldbus)
Customs tariff number 85366990990
Country of origin US
Weight 705 g

Technical Data

Electrical connection M12 receptacle
Protection class IP67
