Product T18RW3FF100 W/30
Field-Wireable Connector
Design A
Order number: 8028723- Screw-clamp terminal
- 2-pin + PE
- Cable feedthrough: 6…8 mm
- Conductor cross-section: 3 × 1 mm2
- Central screw: M3 × 33.5
- Screw-in thread: M20 × 1.5
- Protection class: IP65
- Scope of delivery:
- Valve connector, central screw, pressure screw, seal, sealing ring and pressure ring
