Product NI4-DS20-2AP6X2-H1141
LED Signal Light
Compact Signal Tower
Order number: 3091341Alternative order number : 91341
- Plastic housing, black
- EMI and RFI immune
- Protection class IP67
- M12 x 1 male
- Monochrome: Red (COL 1)
- Operating voltage: Operating voltage 12…30 VDC or 21…27 VAC with 135 mA per LED color
- Inputs: PNP/NPN
General data
| EAN | 662488913410 |
| eCl@ss-Code (V5.1.4): | 27371201 -/- Indicator |
| Customs tariff number | 85318070000 |
| Country of origin | US |
| Weight | 136 g |
Technical Data
| Design | Smooth barrel |
| Operating voltage | 21…27 VAC / 12…30 VDC |
| Electrical connection | Connector, M12 × 1 |
| Housing material | Plastic, ABS, Black |
| Ambient temperature | -40…+50 °C |
| Protection class | IP67 |
Mounting accessories
|
RKS4.4T-1.5-WSS4.4T/TXL | 6628914 |
|
WSC4.4T-0.3/TEL | 6625094 |
|
BI2-EG08K-AN6X
Cylindrical, threaded barrel, 8 mm, stainless steel |
4669500 |
Connectivity accessories
|
TI-BL20-E-EN-S-6
BL ident interface set |
7030632 |
