Product BI4U-M12-AP6X
Accessories
Thermowell
For Temperature Sensors
Order number: 9910428- Thermowell for mounting temperature probes
- End tip diameter 3 mm
- Process connection 1/4" NPT male thread
- Immersion depth 200 mm
- Stainless steel
General data
| EAN | 4047101544268 |
| eCl@ss-Code (V5.1.4): | 27200213 -/- Thermowell (temperature measurement) |
| Customs tariff number | 73072910900 |
| Country of origin | IT |
| Weight | 53 g |
Technical Data
| Design | Accessories |
| Housing material | Stainless steel, 1.4404 (AISI 316L) |
