Product BIM-M12E-Y1X
Safety Light Curtain
Emitter
Cascadable
Order number: 3809177- Rugged housing
- Protection class IP67
- Diagnosis display for status and error indication
- Scan field L: 1820 mm
- Optical Alignment aid
- No blind zone
- Range: 0.1…12 m
- Resolution: 40 mm
- Operating voltage: 24 VDC
- Automatic cascade configuration
- Safety light curtain type 4 acc. to IEC 61496-1 and 61496-2
- Category 4 Ple acc. to EN ISO 13849-1
- SIL 3 acc. to IEC 61508 SIL 3 and CL3 acc. to IEC 62061
- Shock and vibration resistant acc. to IEC 61496-1
- The device is supplied without wiring or mounting brackets. Wiring and mounting brackets must be selected under connection or mounting accessories and are required to operate the device.
General data
| EAN | 662488074319 |
| eCl@ss-Code (V5.1.4): | 27270910 -/- Light grid |
| Customs tariff number | 85365019000 |
| Country of origin | US |
| Weight | 3946 g |
Technical Data
| Design | Rectangular |
| Operating voltage | 20.4…27.6 VDC |
| Electrical connection | Flat connector |
| Housing material | Metal, AL, Black |
| Ambient temperature | -20…+55 °C |
| Protection class | IP67 |
Mounting accessories
|
T30UINB W/30 | 3055985 |
|
|
SLLR14-1540-S | 3809132 |
|
WLS28-2XW285SPWMQ | 3090470 |
|
WKC4.5T-P7X3.1-5/TXO3701 | 6635719 |
|
RJ45S-FKSDD-4422-5M | 6636972 |
|
SM312CVBQDP | 3049073 |
Functional accessories
|
PT600R-2008-I2-H1141/X | 6836672 |
