Product  IM12-FI01-2SF-2I-C0/24VDC/CC

Frequency Transducer/Pulse Counter

2-channel

Order number: 7580231
    • Input circuits monitored for wire-break and short-circuit
    • Parameterized via PC
    • Complete galvanic isolation
    • Removable spring type terminals
    • ATEX use in Zone 2, cUL
    • SIL 2
#

General data

EAN 4047101420388
eCl@ss-Code (V5.1.4): 27230220 -/- Rotation speed monitor
Customs tariff number 85437090990
Country of origin DE
Weight 168 g

Technical Data

Signal type Frequency input
Device type Rotation speed monitor
Ex version no
Approvals cULus
Functional safety (SIL/PL) SIL2
Nominal voltage 24 VDC
Number of channels 2
Electrical connection Removable spring-type terminals, 2-pin
Protection class IP20
Product series IM(X)12

Mounting accessories

6825482
7525110
