Product BKWM14-E01-10/TEL
piconet stand-alone module for DeviceNet
8 Digital PNP Inputs Filter 3 ms
Order number: 6824459- Configuration interface
- Parameterizable functions
- Supported via I/O‐ASSISTANT 2
- Integrated bus T-piece
- Direct connection to the fieldbus
- Fibre-glass reinforced housing
- Shock and vibration tested
- Encapsulated module electronics
- Metal connector
- Degree of protection IP67
General data
| EAN | 4047101181784 |
| eCl@ss-Code (V5.1.4): | 27250302 -/- Digital I/O module (periphery) |
| Customs tariff number | 85176200000 |
| Country of origin | DE |
| Weight | 297 g |
Technical Data
| Network protocol | DeviceNet |
| Approvals | cULus |
