Product PKWH4M-P7X2-0.3-PSGH4M/TFG
Terminating Resistor for Constructing an RFID Line Topology
Order number: 6934907- M12 female, 4-pin
- 120 Ohm resistance between pin 2 and pin 4
- RoHS-compliant
- Protection class IP67
General data
| EAN | 4047101376609 |
| eCl@ss-Code (V5.1.4): | 27279201 -/- Connectivity (accessories sensors) |
| Customs tariff number | 85332100000 |
| Country of origin | CN |
| Weight | 15 g |
Technical Data
| Application | RFID, Data |
| Connector A | Female, M12 × 1 |
| Number of pins | 4 |
| Connector body | TPU, Black |
| Coupling nut/screw | Brass, CuZn, Nickel-plated |
| Network protocol | DeviceNet, RFID |
Mounting accessories
|
PS01VR-501-2UP8X-H1141 | 6831832 |
