Product PT150PSIG-1014-I2-H1141/X
piconet stand-alone module for PROFIBUS-DP
1-channel SSI Sensor Interface
Order number: 6824444- SSI encoder interface
- 1‐channel
- Configuration interface
- Parameterizable functions
- Supported via I/O‐ASSISTANT 2
- Direct connection to the fieldbus
- Fibre-glass reinforced housing
- Shock and vibration tested
- Encapsulated module electronics
- Metal connector
- Degree of protection IP67
General data
| EAN | 4047101181647 |
| eCl@ss-Code (V5.1.4): | 27250307 -/- Technology module (periphery) |
| Customs tariff number | 85369095000 |
| Country of origin | DE |
| Weight | 1 g |
Technical Data
| Ambient temperature | 0…+55 °C |
| Protection class | IP67 |
