Product RSSD-RJ45S-4422-5M
Photoelectric Sensor
Touch Switch
For Two-Hand Control System
Order number: 3064180Alternative order number : 64180
- 7/8’’ male , 4-pin
- Protection class IP66
- Ergonomically shaped
- Upper housing part of polyetherimide
- Operating voltage: 10…30 VDC
- 1 safety NO output PNP
- 1 safety NC output PNP
- Pre-assembled protective cover
- Safety category 4 according to EN ISO 13849-1 for use with corresponding evaluation relays
- SIL 3 acc. to IEC 61508 and IEC 62061
General data
| EAN | 662488641801 |
| eCl@ss-Code (V5.1.4): | 27371690 -/- Relay (safety technology) |
| Customs tariff number | 85365019000 |
| Country of origin | CN |
| Weight | 215 g |
Mounting accessories
|
PS01VR-501-2UP8X-H1141 | 6831832 |
