Product PKG3M-15/TEL
Connection Cable
Order number: 100031025- M12 male connector, K-coded, straight, 5-pin (4+PE)
- Cable length: 2.0 m
General data
| EAN | 4047101559705 |
| eCl@ss-Code (V5.1.4): | 27230209 -/- Current supply, voltage |
| Customs tariff number | 85444290900 |
| Country of origin | CZ |
| Weight | 1 g |
Technical Data
| Application | Power |
| Design | Connection Cable |
| Connector A | Male, M12 × 1, Straight, K-coded |
| Number of pins | 4+PE |
| Connector body | Plastic, TPE, Black |
| Coupling nut/screw | Brass, CuZn, Nickel-plated |
| Voltage | 600 V |
| Cable length | 2.0 m |
| Protection class | IP65, IP67, IP69K |
