Product VAS02-A80E-5/TEL
Isolating switching amplifier
4-channel
Order number: 100028616- 4-channel
- 5 relay outputs
- Separate relay output for group fault signals (NO)
- Configuration via rotary and DIP switches
- 4-channel operation or signal multiplexing (switchable)
- Adjustable output mode (NO/NC)
- Input circuits monitored for wire break/short circuit (can be switched ON/OFF)
- Complete galvanic isolation
- Input reverse-polarity protected
- Removable spring-type terminals
- Power-Bridge (connector incl. in delivery)
- ATEX, IECEx
- Use in Zone 2
- SIL 2
General data
| EAN | 4047101541212 |
| eCl@ss-Code (V5.1.4): | 27210121 -/- Isolating switching amplifier |
| Customs tariff number | 85437090990 |
| Country of origin | DE |
| Weight | 228 g |
Technical Data
| Approvals | ATEX, IECEx |
Data Sheets
| German | 110 KB |
| English | 110 KB |
| French | 110 KB |
| Spanish | 110 KB |
| Czech | 110 KB |
| Dutch | 110 KB |
| Romanian | 110 KB |
| Russian | 115 KB |
| Polish | 111 KB |
| Chinese | 160 KB |
| Turkish | 111 KB |
Approval
| TÜV 14 ATEX 147004 X | 435 KB |
| IECEx — TUN 14.0040X | 1363 KB |
| Kosha — 23-AV4BO-0410X | 4061 KB |
| SIL TÜV Certificate | 888 KB |
