Product BIM-NST-AP6X-H1141/S34
LED Signal Light
Beacon with Audible Signal
Order number: 3079484Alternative order number : 79484
- LED all-round visible
- Continuous signal: 95dB
- Individually controllable
- Protection class IP50
- Multicolor: Green (COL 1) / Red (COL 2) / Yellow (COL 3)
- Male M12 x 1, 5-pin
- Operating voltage 18…30 VDC
General data
| EAN | 662488794842 |
| eCl@ss-Code (V5.1.4): | 27371201 -/- Indicator |
| Customs tariff number | 85318070000 |
| Country of origin | US |
| Weight | 308 g |
Technical Data
| Design | Dome |
| Construction size | 136.6 x 80.9 x 66.7 mm, K80L |
| Operating voltage | 18…30 VDC |
| Electrical connection | Connector, M12 × 1 |
| Housing material | Plastic, PC, Yellow |
| Ambient temperature | -20…+50 °C |
| Protection class | IP50 |
Mounting accessories
|
S30AW3FF200Q1 | 3033364 |
|
PT500PSIG-2005-IX-H1143/X | 100022576 |
|
NI4-Q12-AZ31X
Rectangular, plastic |
13102 |
|
TL5010KQ | 3804915 |
