Product SI-RFPT-L2M
Inductive Sensor
For Rotary Actuators
Order number: 4290004- Rectangular, housing DSU26
- Plastic, PP-GF30-VO
- Two outputs for monitoring the position of rotary actuators
- Mounting on all standard actuators
- AC 4-wire, 20…250 VAC
- DC 4-wire, 10…300 VDC
- 2 normally open contact
- Terminal chamber
General data
| EAN | 4047101094503 |
| eCl@ss-Code (V5.1.4): | 27270101 -/- Inductive proximity switch |
| Customs tariff number | 85365080000 |
| Country of origin | DE |
| Weight | 164 g |
Technical Data
| Design | Dual sensor for rotary actuators |
| Operating voltage | 20…250 VAC / 10…300 VDC |
| Output function | 2 x NO contact, 2-wire |
| Electrical connection | Terminal chamber |
| Housing material | Plastic, PP-GF30, Yellow |
| Ambient temperature | -25…+70 °C |
| Protection class | IP67 |
Functional accessories
|
PS003A-508-2UPN8X-H1141 | 6832722 |
