Product INU.P.SAFETY-ISD_SSA_CONNECTOR.IT
Light Screen for Machine Safety Applications
Emitter/Receiver Pair
Order number: 3073551Alternative order number : 73551
- M12 × 1 male connector, 8-pin
- Protection class IP65
- Scan field 1200 mm
- Resolution 30 mm
- Internal testing in 500-ms cycle
- Range 15 m
- Operating voltage 24 VDC ± 15 %
- Switching output without restart interlock (TRIP)
- Type 2 acc. to IEC 61496-1, -2; category 2 PL d acc. to EN ISO 13849-1; SIL 2 acc. to IEC 61508
General data
| EAN | 662488735517 |
| eCl@ss-Code (V5.1.4): | 27270910 -/- Light grid |
| Customs tariff number | 85365019000 |
| Country of origin | CN |
| Weight | 3243.18 g |
