Product TX800L-P3WV01
Field-Wireable Connector
Male Connector M12 × 1, Angled
Order number: 6932581- A-coding
- Metal housing
- Shieldable
- Shield ring
- Die-cast threaded ring
- Screw-clamp terminal
- 4-pin
- Cable feedthrough 6…8 mm
- Core cross-section 0.14…0.75 mm2

General data
| EAN | 4047106163433 |
| eCl@ss-Code (V5.1.4): | 27279201 -/- Connectivity (accessories sensors) |
| Customs tariff number | 85366990990 |
| Country of origin | DE |
| Weight | 66 g |
Technical Data
| Device type | Field-wireable connector |
Data Sheets
| German | 365 KB |
| English | 364 KB |
| French | 365 KB |
| Spanish | 1538 KB |
| Czech | 367 KB |
| Dutch | 364 KB |
| Romanian | 365 KB |
| Polish | 367 KB |
| Chinese | 387 KB |
| Turkish | 366 KB |
Approval/Declaration
| UL Approval | 400 KB |
| CE Declaration of Conformity | 120 KB |
| RoHS and REACH Manufacturer's Declaration | 280 KB |
