Product IMX12-CCM05-MTI-1I2T-HC/L/CC
Cabinet Guard
Internal Sensors
Order number: 100030580- 2 potential-free contacts
- Temperature detection
- Moisture detection
- Detection of distance to control cabinet door
- Galvanic isolation of outputs (A1/A2)
- Removable spring-type terminals
- ATEX, IECEx
General data
| EAN | 4047101558470 |
| eCl@ss-Code (V5.1.4): | 27189253 -/- Überwachungssystem (Schaltschrank) |
| Customs tariff number | 84702900000 |
| Country of origin | DE |
| Weight | 143 g |
Technical Data
| Device type | Cabinet guard |
| Ex version | yes |
| Approvals | ATEX, IECEx |
| Nominal voltage | 24 VDC |
| Electrical connection | Removable spring-type terminals, 2-pin |
| Protection class | IP20 |
| Product series | IM(X)12 |
Data Sheets
| German | 174 KB |
| English | 171 KB |
| French | 171 KB |
| Spanish | 173 KB |
| Czech | 173 KB |
| Dutch | 170 KB |
| Romanian | 171 KB |
| Russian | 191 KB |
| Polish | 173 KB |
| Chinese | 228 KB |
| Turkish | 173 KB |
