Product RKS56PKB-3-RSS56PKB/TXL
piconet stand-alone module for DeviceNet
1-channel Serial Interface RS232/RS485
Order number: 6824097- Serial interface RS422/485
- 1‐channel
- Configuration interface
- Parameterizable functions
- Supported via I/O‐ASSISTANT 2
- Direct connection to the fieldbus
- Fibre-glass reinforced housing
- Shock and vibration tested
- Encapsulated module electronics
- Metal connector
- Degree of protection IP67
General data
| EAN | 4047101178227 |
| eCl@ss-Code (V5.1.4): | 27250307 -/- Technology module (periphery) |
| Customs tariff number | 85176200000 |
| Country of origin | DE |
| Weight | 241 g |
Technical Data
| Network protocol | DeviceNet |
| Approvals | cULus |
