Product TS700-L050-16-LI2UPN8-H1141
Plastic Fiber
Single Conductor — Jacketed Optical Cable Made of Plastic Fiber
Order number: 3025905Alternative order number : 25905
- Operation: opposed mode
- 2 pcs. included in delivery
- Polyethylene sheath, flexible
- Operating temperature: -30…+70 °C
- Cable, straight, customizable
- End sleeve for sensor, angled (90°)
- Optical fiber, core diameter 0.5 mm
- Optical fiber, total length: ± 1829 mm
General data
| EAN | 662488259051 |
| eCl@ss-Code (V5.1.4): | 27061090 -/- Ready-made optical fiber (not classified) |
| Customs tariff number | 85447000990 |
| Country of origin | JP |
| Weight | 34 g |
Technical Data
| Design | Circular |
| Housing material | Plastic, PE, Black |
| Ambient temperature | -30…+70 °C |
Connectivity accessories
|
PT300PSIG-2014-U1-DA91/X | 6837037 |
|
SLPCR25-690P8 | 3083623 |
|
PK010R-N12AL-2UP8X-V1141 | 6833010 |
|
RSSW-RKSW-X2X-17M | 100048928 |
