Product M12FTH4Q
Temperature and Humidity Sensor
With Serial Interface
For Connecting to a DX80 Radio Node
Order number: 3025895Alternative order number : 25895
- Robust metal housing
- Ambient temperature: -40…+85 °C
- Protection class IP67
- Relative humidity: 0…100 %
- Resolution: 0.1 %
- Temperature measuring range: -40…+85 °C
- Resolution: 0.1 °C
- Operating voltage: 3.6…5.5 VDC
- Serial interface to connect a DX80 radio participant
General data
| EAN | 662488258955 |
| Customs tariff number | 90258040890 |
| Country of origin | US |
| Weight | 68.04 g |
Technical Data
| Function | Temperature/humidity sensor |
| Device type | Sensor |
| Design | Tube |
| Antenna connection | No radio participant |
| Communication protocol | 1-wire-serial |
| Electrical connection | Connector, M12 × 1 |
| Housing material | Metal, Grey |
| Ambient temperature | -40…+85 °C |
| Protection class | IP67 |
